Shaft collars

fully turned steel, surface treatments, short leadtime, customised versions

Founded in 1967 by Dante Cavalli, under the name OMC, the company originally manufactured mechanical transmission components. In 2010 the company name was changed to ComInTec, to better reflect how the product range has developed over the years. The range now includes power transmission components, torque limiters, safety couplings, backlash free torque limiters, elastic couplings, disc couplings, backlash free couplings, variable speed pulleys, expanding pulleys, shaft collars and clamp collars. These components provide transmission connections, avoid accidental overloads, reduce machine stoppage times, increase productivity, and reduce maintenance and repair costs. Sold globally, the Comintec products are used in a wide variety of application and market sectors, and renowned for quality and reliability.

CFU

Shaft Collar

Provides a stop location for positioning of bearings, shaft assemblies and other shaft components. Available in both mild steel and stainless steel. Special surface treatments for anti-corrosion resistance are available on request.

  • Fully Turned Steel
  • According to DIN705
  • Stainless Steel Available
  • Deburred Edges
  • Surface Treatments Available
  • Stainless Steel (on request)

Technical
Downloads
Linked Products
Bore Diameter3mm - 70mm
Body Diameter8mm - 100mm
Width5mm - 20mm
Thread SizeM2.5 - M10
Fully TurnedYes
Deburred EdgesYes
Corrosion ResistantOn-Request
Customised VersionsOn-Request
CatalogueShaft Collar & Washers BrochurePDF 2.2MB
.
Stainless Steel FlierPDF 1.7MB
.
Dimensions2D & 3D Configuratorhttp://www.tracepartsonline.net/(S(vyfvkjgks0bt5kl3kyfcehp5))/content.aspx?fwsid=COMINTEC&Lang=en&ttl=&st=0
