Hydraulic Cylinder position sensors

compact design, suitable for harsh environments, easy installation, long lifetime

SIKO has more than five decades of experience in length, angle and speed measurement. Due to high demands from their customers, in both the industrial and mechanical engineering sectors, this has resulted in outstanding quality, precision and functionality of the Siko products. Certified to ISO 9001 : 2008, Siko is a global company with five subsidiaries and approximately 60 worldwide distributors, ensuring direct sales and technical support to customers both nationally and internationally. Globally, Siko employ more 200 staff. Siko’s measurement technology product portfolio encompasses five product ranges: Digital position indicators and hand wheels (PositionLine), Rotary encoders, geared potentiometers and measurement indicators (RotoLine), Wire-actuated encoders (LinearLine), Actuators (DriveLine) and Magnetic measuring systems (Magline). Continually innovating, Siko is at the forefront of sensing and measurement technology.

cylinder sensors

Hydraulic Cylinder Position Measurement

Siko's unique range of Hydraulic Cylinder measurement sensors are fully integrated inside the cylinder body, thanks to their compact and clever design. This means that they can be used in very harsh environments yet still offer maintenance free operation and long life. Additional, the expensive and time consuming drilling of the pistion rod is now no longer necessary, meaning installation is very simple and fast.

  • Extrememely Robust
  • Long Lifetime
  • Maintenance Free Operation
  • High Tolerance to Vibration and Shocks Loads
  • Suitable for Safety Critical applications

Technical
Downloads
Linked Products
Measuring LengthUp To 5m
Housing MaterialAluminium
InterfacesCurrent
Voltage
CANopen
CANopen Safety
SAE J1939
Redundant Analogue
Redundant CANopen
Redundant SAE J1939
Wire MaterialStainless Steel
CataloguesSGH10 DatasheetPDF 1.06MB
.
SGH25 DatasheetPDF 452KB
.
SGH50 DatasheetPDF 429KB
.
SGH10L DatasheetPDF 280KB
.
KV1H DatasheetPDF 230KB
.
SVH DatasheetPDF 444KB
.
ZB4004 Installation Tool DatasheetPDF 228KB
.
ZB4005 Installation Tool DatasheetPDF 216KB
.
ZB4008 Installation Tool DatasheetPDF 216KB
.
ZB4009 Rope Swivel DatasheetPDF 233KB
.
Protool SGH DatasheetPDF 990KB
.
Hydraulic Position Sensor FlierPDF 3.8MB
.
Wire Actuated Encoder Main CataloguePDF 2.6MB
.
Siko Product Overview BrochurePDF 3.4MB
.
Industry SectorIndustrial TrucksPDF 3.8MB
.
Construction CranesPDF 4.8MB
.
Hydraulic CylindersPDF 3.4MB
.
Mobile MachinesPDF 1.7MB
.
ManualsSGH10 Installation InstructionsPDF 3.0MB
.
SGH10 Quick Start GuidePDF 1.0MB
.
SGH10 CANopen ManualPDF 1.3MB
.
SGH25 Installation InstructionsPDF 3.2MB
.
SGH25 Quick Start GuidePDF 1.2MB
.
SGH25 CANopen ManualPDF 1.3MB
.
SGH25 CANopen-Safety ManualPDF 1.8MB
.
SGH50 Installation InstructionsPDF 3.4MB
.
SGH50 Quick Start GuidePDF 1.2MB
.
SGH50 CANopen ManualPDF 1.4MB
.
SGH50 CANopen-Safety ManualPDF 1.8MB
.
Protool SGH Quick Start GuidePDF 1.3MB
.
Protool SGH Installation InstructionsPDF 3.0MB
.
SoftwareProtool SGHZIP 1.4MB
.
TutorialHow To Video - Protool SGHN/Ahttps://www.youtube.com/watch?v=wgvXWV4DzrI
Dimensions2D & 3D Configuratorhttps://siko-embedded.partcommunity.com/3d-cad-models/sso/position-sensors-for-hydraulic-cylinders-siko?info=siko%2Flinearline%2Fpositionssensoren_fuer_hydraulikzylinder
CertificatesISO 9001 Quality CertificatePDF 680KB
.
RoHS/Reach/WEEE DeclarationPDF 239KB
.
