VFD-EL

Frequency Inverter

General purpose Frequency Inverter offering good level of functionality. Configurable with V/F and Vector control, switchable l/O logic, optional fieldbus modules, IT mains switch, DC bus sharing and side-by-side mounting.

  • General Purpose Inverter
  • 0.2kW to 3.7kW
  • 1ph/115V, 1ph 230V, 3ph/460V
  • Integrated EMC Filter
  • Integrated Keypad

Technical
Downloads
Linked Products
Power Range0.2 - 3.7kW
Supply1ph/230VAC
1ph/115VAC
3ph/460VAC
Switching LogicNPN / PNP - Switchable
EMC FilterIntegrated
PLCNo
KeypadIntegrated
Output Frequency0.1 - 600Hz
Fieldbus OptionsCanOpen
Profibus
DeviceNet
Control TypeV/F
Sensorless Vector
CatalogueDelta VFD-EL Compact Drive CataloguePDF 3.1MB
.
Delta Overview Drives CataloguePDF 2.59MB
.
Technical ManualDelta VFD-EL User ManualPDF 8.8MB
.
EMC Standard Installation GuidePDF 469KB
.
SoftwareDelta VFDSoft V1.58ZIP 33.7MB
.
Delta VFDSoft ManualZIP 6.0MB
.
DimensionsFrame A - 2D PDFPDF 146KB
.
Frame A - 2D DWGZIP 524KB
.
Frame A - 2D STPZIP 2.2MB
.
Frame B - 2D PDFPDF 156KB
.
Frame B - 2D DWGZIP 544KB
.
Frame B - 2D STPZIP 3.2MB
.
CertificationsCE CertificatePDF 535KB
.
UL CertificatePDF 113KB
.
C-TICK CertificatePDF 32KB
.
RoHs CertificatePDF 32KB
.
